Unifiber™ Quattro Optical Receiver (300-2350 MHz) (6126)
Κωδικός:
IDLF-RXQTO1-W2923-OPR
Inverto
Quattro Optical Receiver (300-2350 MHz) with wideband (V+H) and DTT outputs
The Unifiber™ Quattro optical receiver connects to an Inverto's Unifiber™ optical transmitter over a fiber passive-optical-network to receive satellite and terrestrial signals combined over a single fiber cable. A status LED helps installers to validate the power of the optical signal and guarantee the quality of the RF signals at the outputs of the receiver. This Quattro receiver features four Quattro ports (VL, VH, HH, HL), two wideband ports (vertical and horizontal) and an independant DTT port supporting all FM, DAB and DTT broadcasts. The receiver can be powered via the satellite output ports or through an external power supply via the DC in port. The compact and robust die-cast housing makes it ideal for riser/shaft installations addressing fiber-to-the-building applications.
Main Features:
- Optical Quattro receiver with independent Wideband and DAB/DTT outputs (UK version)
- Built-in high dynamic range optical AGC (-15~-5dBm) increasing signal quality
- Optical wavelength 1100-1650 nm, compatible with Inverto's Unifiber™ transmitters
- Wideband frequency range 300 ~ 2350 MHz
- Quick and easy install, powered from external power supply or satellite ports
- Compact, robust die-cast housing, for indoor installations (IP54)
| Technical specifications | |
|---|---|
| Optical input | |
| Wavelength | 1100 ~ 1650 nm |
| Optical input level (with AGC) | -15 ~ -5 dBm |
| Optical port | 1, FC/UPC |
| Satellite Quattro outputs | 4x VL, VH, HH, HL color coded; F-type |
| Output frequency range | 2x 950 ~ 2150 MHz + 2x 1100 ~ 2150 MHz |
| Output power level | -28 dBm (80dBuV) |
| Output level variation | 4 dB max. |
| Power supply | 10 - 20 VDC |
| Return loss | 10 dB min. |
| Impedance | 75 Ω |
| Satellite wideband outputs | |
| Output ports | 2x Horizontal, Vertical; F-type |
| Output frequency range | 300 ~ 2350 MHz |
| Output power level | -28 dBm (80dBuV) |
| Output power supply | 10 - 20 VDC |
| Return loss | 10 dB min. |
| Impedance | 75 Ω |
| DTT outputs | |
| Output ports | 1x, F-type |
| Frequency range | FM/DAB/VHF 88 ~ 240 MHz UHF 470 ~ 790 MHz |
| Output power level | -28 dBm (80dBuV) |
| Output level variation | 4 dB max. |
| Return loss | 8 dB min. |
| Impedance | 75 Ω |
| Power supply | |
| Power supply - via DC in | 10 - 20 V DC, 3.5/1.3 mm DC jack |
| Power consumption | 2.5 W max. |
| Earthing terminal | Yes |
| Optical input level LED | Green = OK, RED = High optical input power, Yellow=Low optical input power |
| Operating temperature | -20°C ~ +50°C |
| Dimenssions | 149 x 89 x 26 mm |
| Weight | 360 g |
