Unifiber™ 4-way optical splitter cassette, SC/APC (5891)
Κωδικός:
IDLF-OSPOO1-SCA08-PPT
Inverto
Inverto’s Unifiber™ range of balanced passive optical splitters operate over a wide optical bandpass range 1260-1650nm featuring high uniformity across output ports, low insertion loss, high return loss and excellent directivity performances. The Unifiber™ optical splitters are offered in a cassette housing and fitted with SC/APC connectors.
Cost effective and highly reliable, the Unifiber optical splitters are ideal for indoor FTTx/PON/CATV applications.
Unifiber™ Optical Splitters highlights
- Balanced, High uniformity across output ports
- High Directivity
- Low Insertion Loss
- High Return Loss
- SC/APC connector type
- High Reliability
| Technical specifications | |
|---|---|
| Fiber type | Single mode G.657A1 |
| Operating wavelength | 1260 nm ~ 1650 nm |
| Input ports | 1x SC/APC |
| Output ports | 4x SC/APC |
| Optical Insertion Loss | 7.8 dB max |
| Optical Return Loss | 55 dB min. |
| Uniformity | 0.7 dB max. |
| Directivity | 55 dB min. |
| Polarization dependent loss | 0.3 dB max. |
| Operating temperature | -40°C ~ +85°C |
| Storage temperature | -40°C ~ +85°C |
| Unit dimensions | 130 mm × 112 mm × 25 mm |
| Weight | 109 g |
